VANTAGE® 400 ENGINE DRIVEN WELDER (PERKINS®) K32038-1

Top Features

  • Compact Case with Stainless Steel Enclosure
  • Multi-Process Welding, Separate Arc Gouge Mode
  • Plenty of AC Generator Power
  • Industrial Diesel Engine - 4 cylinder 1500 RPM Perkins®
  • Innovative Service Access

Processes

  • Stick, TIG, MIG, Flux-Cored, Gouging

Compact, Multi-Process, Excellent Value

  • The quiet, compact Vantage® 400 is an ideal choice for construction teams, pipe rig owners and rental fleet managers Utilising a smooth running 4 cylinder Perkins® diesel engine.

Compact Case with Stainless Steel Enclosure

  • One of the most compact 400 amp machines available. Suitable for many pickup and service trucks.
  • Standard stainless steel roof, side panels and engine-access door deliver added protection and durability.

Multi-Process Welding, Separate Arc Gouge Mode

  • Select one of five Process Modes, including CC-Stick (up to 6mm.), Downhill Pipe (for stick), DC Touch Start TIG®, CV-Wire (up to 2.4mm.) or Arc Gouging mode which maximizes output with up to 8mm carbon rods.

VRD Voltage Reduction Device

  • Reduced OCV in CC and CV weld modes for added safety.

Plenty of AC Generator Power

  • 13.2 kW continuous 3-Phase 415/240V AC generator power. Will power industrial equipment such as a plasma cutter, pump or inverter welder.
  • 1 x 415V 20A and 2 x 240V 15A receptacles for generator power for common construction tools.

Reliable Engine

  • 4 cylinder 1500 RPM Perkins® diesel engines run smooth and quiet. Standard engine gauges allow you to monitor performance at a glance.\
  • 76 litre fuel tank for long run time.

Innovative Service Access

  • Lockable, removable sliding engine access door provides ample space for engine and oil filter work without requiring a large clearance space on your truck.
  • Battery drawer on front of machine and top-mounted radiator cover provide convenient access to these systems.
  • Patented tilt down control panel for easy servicing of internal components.
  • Patented radiator cap cover is latched for easy access and is lockable.

Low Noise

  • 96 dBA Lwa sound power (71 dB at 7 m) – one of the quietest 400 amp engine-driven welders available.

Price Machine Only


Part Number/SKU: K32038-1

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.

Specifications

Part no.

K32028-1

Output Range

30-400A

Duty Cycle

400A, 30V@60% 350A, 34V@100%

Engine Type

Perkins 404C-22 liquid-cooled diesel

Cylinders

4

HP @ RPM

28Hp@1500rpm

Dimensions (mm) H x W x D

913 , 642 , 1524

Net Weight (kg)

560

Operator Manual

ea96efc03b9a050d895110db8c4af057-2.pdf
SKU K32038-1
Brand Lincoln
Shipping Weight 560.0000kg
Shipping Width 1.200m
Shipping Height 1.200m
Shipping Length 1.524m
Shipping Cubic 0.893287000m3
Unit Of Measure ea

3 Years Warranty
