Tap T478 Pg 9-18 6H Straight ISO529 Bott HSS Sutton T4781520

Features

• General Purpose use for materials up to approx. 1000 N/mm2
• Through & blind holes
• Suitable for both hand and machine operations

Specifications

• Designation: N (for normal general purpose type materials)
• Material: High Speed Steel (HSS)
• Finish: Bright
• Max Cut Depth: 1xD
• Shank Form: Reduced Shank (with square drive)
• X: als
• Type: Straight Flute
• Standard: ISO529
• Thread Form: Pg – Steel Conduit (Armour Pipe)
• Nut Tolerance: To Suit
• Lead: Bottoming

Part Number/SKU: T4781520

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.
