Raw air extraction device for (semi) stationary wood processing machines (observe country-specific regulations!)
Significantly reduces dust content
The filter material of dust class L
Integrated grounding as protection from electrostatic charge
Quick change of the application location by means of the wheeled unit and simple connection
Stable stand with the supported chip collection bag
The Comprehensive range of accessories: automatic switch-on devices, filter cartridges, hoses and adapters
The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to the delivery scope and product description.
Accessories included only if listed in the delivery scope.

Characteristics
Dimensions830 x 450 x 1600 mm / 2.8 x 1.5 x 5.3 ft
Maximum vacuum1600 Pa / 0.2 psi
Maximum volume flow900 m³/h / 237755 gal/h
Filter surface1 m² / 1550 sq.inch
Hose connection Ø100 mm / 4 "
Chip bag capacity65 l / 17 gal
Rated input power0.55 kW
Weight22 kg / 48.5 lbs
Cable length3 m
Noise emission
Sound pressure level85 dB(A)
Sound power level (LwA)98 dB(A)
Uncertainty of measurement K3 dB(A)

Part Number/SKU: 601205000
