ArcReach Suitcase 12 Miller MR301456

GAME CHANGING TECHNOLOGIES THAT CAN STOP YOU FROM WASTING HOURS EVERY DAY - IMPROVES SAFETY, PRODUCTIVITY & PROFITABILITY.

ArcReach welding technology minimises the non-valueadded time spent walking to and from the power source - and maximises arc-on time, weld quality and jobsite safety.
Set Volt & Wire Feed Speed Remotely
The simple interface on the feeder allows operators to adjust parameters at the point of use with no control cords.

Durable Design Reduces Downtime
Impact-resistent case and the elimination of feeder control cords provides a solid solution to last in harsh environments.

Increased Uptime
ArcReach feeders and remotes have been extensively field proven and deliver the performance you need with ruggedly constructed internal components.

No more expenses related to maintaining or replacing easily damaged control cords.
Improved Jobsafety
The chances of slip, trip or fall injuries are decreased because ArcReach technology allows welding operators to make parameter changes at the wire feeder/ remote instead of having to travel through multi-story and cluttered jobsites back to the power source.

More Jobsite Productivity & Efficiency
ArcReach capabilities eliminate the time spent tracing weld cables hundreds of feet back to the power source because weld operators can make adjustments at the ArcReach wire feeder or remote.



Cable Length Compensation (CLC™)
Ensures that the voltage a weld operator sets is the voltage they get by automatically adjusting voltage based on weld cable length, even hundreds of feet away from the power source.

* Only available when connected to an XMT 350 FieldPro power source.

Maximum Fleet Compatibility
Maximise fleet compatibility and get the benefits of ArcReach when you pair XMT 350 FieldPro welders and ArcReach feeders with other ArcReach compatible products.

Setting the Standard for Performance
Heavy-duty drive motor with tachometer control provides wire feed speed that is accurate and consistent from the start of the weld to the finish and from one weld to the next, which provides consistent arc quality. Wide voltage range for small and large wires with no contactor chatter or arc outages.

More Operator Control
More control for weld operators with quick, easy adjustments at the wire feeder / remote.

Inadvertent parameter changes by other jobsite workers can be easily avoided.
Return to previous weld process faster.
Decrease the chance of an incorrect weld process being used.

SPECIFICATIONS

 Input Power Operates on Open-Circuit voltage and arc voltage   14-48 VDC/110 Max. OCV
 Input Welding Current Rating   425A at 60% Duty Cycle
 Wire Speed   1.3-19.8 m/min dependent on arc voltage
 ElectrodeWire diameter capacity

 Solid wire 0.6-1.4mm

 Flux cored - 0.8-2.0mm

 Max. Spool Size capacity   305mm Diameter up to 20 Kg
 Dimensions ( H X W X D)  394 x 229 x 533
 Weight   15.9 kg




Part Number/SKU: MR301456

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.

SKU MR301456
Brand Miller
Shipping Weight 20.0000kg
Shipping Width 0.300m
Shipping Height 0.400m
Shipping Length 0.400m
Shipping Cubic 0.048000000m3
Unit Of Measure ea
