Magnetic Base Drill MT2 CAP: 52mm DIA X mm HMPRO52-MT2

FEATURES

• New generation machines with the latest technology and design.
• New Rigid Frame Design
• Provides increased life of cutting tools.
• New Extra Large 165mm Stroke
• Enables the use of long tooling such as extension arbors and large depth cutters for drilling box section steel in one pass, twist drills, reamers, taps etc.
• Magnetic Field Shape Control (MFSC)
• Provides maximum holding power on thin materials.
• Lightweight & Powerful
• The new generation Holemaker machines are lighter and more powerful than other brands on the market.

Features:

• Multi-purpose machine able to use Holemaker cutters, no. 2 Morse taper shank drills & reamers, as well as a drill chuck
• Industrial 2-speed gearbox
• Cast-iron motor housing
• Through spindle coolant system, with an external side mounted gravity feed coolant tank
• Left or right hand feed handle operation
• Unique semi-automatic gib adjustment system enables simple, fast and always correct fine tuning without any expert knowledge or experience
• Smart magnet technology to ensure sufficient magnetic adhesion
• Supplied in a blow mould plastic carry case
• Suitable for steel fabrication, engineering workshops & maintenance facilities where a heavy-duty versatile machine is highly beneficial
• Supplied complete with arbor for use with Holemaker cutters up to 50mm depth of cut (3/4" shank)
• #2MT drill chuck SA20102 available separately

SPECIFICATIONS

• Capacity (Diameter): 52mm
• Capacity (Depth): 52mm
• Capacity (Twist Drills): #2 Morse Taper 23mm
• Motor Power: 1100 Watt
• Input Power: 1200 Watt Single Phase 240V
• Speed: 2 Speed 240 / 480rpm
• Weight: 16.5kg
• Magnetic Dead Lift: 9,900Nm On 25mm Steel Plate
• Stroke: 165mm
• Height (Min. / Max.): 456mm / 616mm

Part Number/SKU: HMPRO52-MT2

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.
