National 1500W Laser Handheld Welder NL1500WA

Product Characteristics:

  • High wall-plug efficiency
  • High power with Excellent beam quality
  • High reliability, long service life, maintenance free

Model Parameters



Parameters

Model  NL1500W
Limit Power (W)(At the current of 19A)  1300W
Maximum Power (W)(the current is 225A)  1500W
Operating Power   Continious welding & Spot Welding
Polarization Direction   Random
Output Power adjustment Range   10-100%
Central Wavelength   1080 +-3nm
Power attenuation after 1 Hour of continious operation  <2%
Maximum Modulation Frequency   5 Khz
Indicating Red Light Power   >=0.2mW
Output fibre core Diameter  20µm
Ouput Armored Cable Length   Default 5M
Operating Volatge   AC 220V Single Phase, 50/60Hz
Maximum Power consumption   <4100W
Control Method   Touch Screen
Dimension (W X H X D)   273 X 634.1 X 527.7 mm
Weight   43 Kg
Operating Temperature  -30~40°C
Operating Humidity   <90%
 Cooling   Air
Storage Temperature  -10-60°C
Inert gas pressure   ≤0.7MPa




Part Number/SKU: NL1500

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.

SKU NL1500
Brand National Laser
Unit Of Measure ea
