FabCOR 86R Metal Cored Gas Shielded 1.2mm 15Kg Flux Cored Wire With Higher Deoxidization Elements Hobart S249412-029

Description
A metal cored wire with a higher deoxidization elements allow this wire to have greater tolerance for mill scale welding applications. Single and multiple pass applications.

• MCAW

• High Deposition Rates and Efficiencies
• Virtually no slag coverage
• Outstanding high-production performance
• Smooth arc characteristics
• Low diffusible hydrogen weld deposit
• Low smoke and spatter levels
• Excellent for both CV and pulsed welding
• Productivity Gain
• Improves productivity compared to solid wire or flux-cored electrodes
• Reduces clean up time, improves productivity
• Excellent for robotic welding
• Improved operator appeal, assists in maintaining consistent weld quality
• Minimises risk of hydrogen-induced cracking
• Improves operator appeal and productivity
• Promotes versatility in procedure development

Typical Applications

• Automatic and mechanised welding,
• storage vessels,
• non-alloyed and fine grain steels,
• steel structures,
• earthmoving equipment,
• general fabrication,
• shipbuilding,
• rail cars.

CLASSIFICATION

• AS/NZS ISO 17632-B - T494T15-)MA-UH5
• AWS A5.18: E70C-6M H4

CONFORMANCES & APPROVALS

• ABS: 80% Ar/20% CO², 3YS
  • (0.035” - 1/16” diameter electrodes)
• Bureau Veritas: 80% Ar/20% CO², S3YMH
  • (1.2mm - 1.6mm diameter electrodes)
• DNV: 80% Ar/20% CO², III Y40MS(H5)
• CE: Marked per CPR 305/201
  • (1.2mm - 1.6mm diameter electrodes)
• Lloyd’s Register: 80% Ar/20% CO², 3Y40S H5
• AWS: D1.8/D1.8M, 75% Ar/25% CO²
  • (1.2mm - 1.6mm diameter electrodes)
