Epoxy General Purpose High Strength 5 min 25ml

DESCRIPTION:

Rapidstick™ 5 Minute Epoxy is a high-strength, versatile, non-shrinking, two-part dual syringe adhesive, which delivers equal parts of both the epoxy resin and the hardener with every use. When mixed, the reaction produces a tough, rigid bond in 5 minutes for quick project completion.
5 Minute Epoxy is ideal for metal and hard material bonding, as well as mold infusion. It can also be used for electronic parts insulation, moisture-proof potting, and privacy masking, and is compatible for use on a wide range of other materials as a gap filler or for surface repairs and laminating. Combining 5 Minute Epoxy with fiberglass cloth creates a durable patch, and tinting with earth pigments, cement, or sand allows color matching. Once dry, it can be rubbed back and drilled.
5 Minute Epoxy is resistant to water and most common solvents, drying clear and making it perfect for transparent repairs, or projects that require invisible seams.
Recommended bonding surfaces include, but are not limited to:

• Metal
• Glass
• Ceramics
• Wood
• Rigid Plastics
• China
• Tile
• Fiberglass
• Concrete
• Stone

PRODUCT LIMITATIONS:

• Not recommended for polyethylene, polypropylene, non-stick coatings, nylon products, or flexible materials
• Not suitable for applications requiring short-term heat exposure greater than 150°C
• Not recommended for applications with prolonged water immersion
• Not suitable for use on potable water systems

APPLICATION:

Note: The dual syringe this product arrives in will ensure that both Parts A and B are dispensed equally, so no manual measurement will be required.
On a clean mixing surface, dispense equal measurements of Part A (Resin) and Part B (Curing Agent). Stir thoroughly clockwise along the inner wall of the mixing surface.
For best results, apply a small amount of adhesive to both surfaces within 1 – 2 minutes of mixing, and press together. Support the bond for up to 10 minutes at room temperature.

TECHNICAL DATA:

APPLICATION PROPERTIES:

• Lowest Recommended Temperature:  15o C
• Humidity:  Max. 85%
• Curing Conditions:  2 grams: 5 mins @ 25oC
• Pot Life;  100 grams: 2 mins @ 25o C
• Gel Time (5g:5g):  4 to 10 minutes*
• Handling Time:  20 minutes*
• Usable Strength (500 psi):  30 minutes*
• Full Cure:  24 hours*

*Dependent upon temperature, humidity, and thickness of epoxy applied

UNCURED ADHESIVES PROPERTIES:

• Color (Resin & Hardener):  Colourless to clear amber
• Base:  Epoxy Resin / Polymercaptan Hardener
• Odor:  Mind amine
• Specific Gravity:   Resin: 1.15, Hardener: 1.05
• Viscosity;   Resin: 8,000 – 12,000 cps, Hardener: 5,500 – 8,500 cps
• Flash Point:   Resin: >249°C, Hardener: >93°C
• VOC Content (Resin & Hardener):   0.1% by weight (CARB)
• Shelf Life (unopened)  24 months from date of manufacture
• Resistance to Freezing:  Undamaged by freezing

Note: If the product is frozen, warm it to room temperature until the resin and hardener become liquid enough to mix

CURED ADHESIVES PROPERTIES:

• Colour & Form:  Colourless, non-flammable solid
• Service Temperature (Continuous/Long-Term):  -23oC to +49oC
• Service Temperature (Intermittent/Short-Term):  -23oC to +150oC
• Water Resistant:  Yes
• Sandable:  Yes
• Paintable:  No
• Hardness (Shore D):  82
• Voltage Resistance:  22 KV/mm
• Bending Strength:  25Kg/mm2
• Volume Resistance:  1x1015 Ohm3
• Surface Resistance:  5x1015 Ohm-m2
• Thermal Conductivity:  0.56 W/M.K
• Electricity Loss:  0.42 per 1KHZ
• Heat Distortion Temperature:  140oC
• Water Absorption:  < 0.15%
• Compressive Strength: 11.4Kg/mm2

The above typical performance data are measured in a laboratory environment with a temperature of 25oC and a humidity of 70%.

PRODUCT PERFORMANCE TESTING:

FIRST AID AND SAFETY PRECAUTIONS:

Always refer to Safety Data Sheet/s before use. Use proper Personal Protection Equipment. Do not get in the eyes, on the skin, or clothing. Use with adequate ventilation. Avoid breathing fumes. Keep away from heat, sparks, open flames, and hot surfaces. This product may produce adverse health conditions, ranging from minor skin irritation to serious systemic effects. It should not be used, stored, or transported until the handling precautions and recommendations as stated in the Safety Data Sheet/s for this product have been fully understood by all persons who will work with the material.

STORAGE AND TRANSPORT:

Refer to Safety Data Sheet/s for recommendations. As a general precaution, keep containers tightly closed, protect them from sunlight, and do not expose them to temperatures exceeding 50°C. Containers should be secured and stored upright during transit.

Part Number/SKU: 8-150-25
