CS 22-355 Metal Chop Saw Metabo 601786190

  • Powerful metal chop saw for cutting of profiles, pipes and rods made of steel, NF metals, iron and cast profiles
  • Quick clamping device with variable mitre setting for angled cuts from -15° to 45°
  • Large handle transversal to the cutting axis for optimum power transmission while cutting
  • Adjustable cutting depth limiter for optimum use of the cutting disc
  • Easy, fast disc change with spindle lock
  • Maximum user safety: swivelling cutting guard, adjustable spark deflector sheet and rubberised base for safe cutting
  • Safety switch for protection against accidental start up
  • Robust, large machine table with practical storage for hexagonal wrenches
  • Easy to transport due to built-in handle and locking device


Characteristics
Grinding wheels (Ø x bore)                                    355 x 25.4 mm // 13 31/32 x 1 "
No-load speed                                                        3700 rpm
Rated input power                                                  2300 W
Max. cutting capacity round tube                           132 mm / 5 3/16 "
Max. cutting capacity square tube                          120 x 120 mm // 4 23/32 x 4 23/32 "
Max. cutting capacity rectangular tube                   100 x 208 mm // 3 15/16 x 8 3/16 "
Max. cutting capacity L-profile                                150 x 150 mm // 5 29/32 x 5 29/32 "
Dimensions of the base plate                                  456 x 256 mm // 17 15/16 x 10 1/16 "
Transport height                                                      394 mm / 15 1/2 "
Weight                                                                     16.8 kg / 37 lbs
Cable length                                                             4 m / 13 ft



Part Number/SKU: 601786190

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.

SKU 601786190
Brand Metabo
Shipping Weight 17.0000kg
Shipping Width 0.400m
Shipping Height 0.400m
Shipping Length 0.650m
Shipping Cubic 0.104000000m3
Unit Of Measure ea
